F 1200
F 1200 basic hardware Cranked turn-and-tilt hardware for manual ventilation of rooms and staircases
- Ventilation with variable adjustment – from gap ventilation to the tilted end position
- Functional safety due to weight-independent crank handle activation with control display
- Additional protection against incorrect operation and overload friction coupling
- Secure locking due to the arrangement of virtually any number of bolt positions on all four sides
- All fitting parts are positioned on the inner leaf shell
Application Areas
- Ventilation of rooms and stairways
- Large and heavy windows up to 200 kg leaf weight
- Inward opening rectangular windows bottom-hung and side-hung leaves
- Outward-opening top-hung leaf:
- Installation on wooden, PVC or metal windows
- Leaf installation
Technical data
| F 1200 basic hardware | |
| Leaf width (min.) | 750 mm |
| Leaf height (min.) | 750 mm |
| Leaf weight (max.) | 200 kg |
Downloads
Basic fitting F 1200
LABELLING OBLIGATION:
© GEZE GmbH
F 1200 in vertical operation
LABELLING OBLIGATION:
© GEZE GmbH
F 1200 scissor hinge
LABELLING OBLIGATION:
© GEZE GmbH
