Combined detector
GC 365 Combined detector for activating and protecting automatic sliding doors with four different infrared light curtain configuration settings
- Radar movement detector with active infrared light curtain and third presence detection
- Reliable detection up to an installation height of 3500 mm
- Four adjustable light curtain configurations without additional light prisms
- Fewer total sensors are required due to the large detection area on the floor
- Look back function secures the area between the door leaves during the hold-open time
- Installation and parameter setting information provided directly in the sensor housing
Application Areas
- Activation and protection of automatic sliding doors
- Interior and exterior doors
Technical data
| GC 365 | |
| Dimensions | 267 x 61 x 38 mm |
| Technology | Electromagnetic radar waves/active infrared beams |
| Number of active infrared detectors | 3 |
| Operating voltage | 12-30 V DC / 12-24 V AC |
| Operating current | 100 mA |
| IP rating | IP54 |
| Connection type | System plug-type connector |
| Connector cable length | 3000 mm |
| Installation height (min.) | 2000 mm |
| Installation height (max.) | 3500 mm |
| Weight | 270 g |
| Service temperature | -20 - 55 °C |
| Humidity | 0-80 % relative, non-condensing |
| Standard conformity | DIN 18650, EN 16005 |
