2-leaf systems
Powerturn F-IS Electromechanical swing door drive system for 2-leaf fire and smoke protection doors with closing sequence control
- Smart swing function for easy manual door opening
- Closing force of EN4-7 with variable adjustment
- Opening and closing speed can be individually adjusted
- Mechanical latching action when operated without current, and electrical latching action in regular operation, which accelerates the door shortly before the closed position
- Mechanical and electrical closing sequence control holds the active leaf in the waiting position until the passive leaf is closed
- Low-energy function opens and closes the door with reduced speed, fulfilling the highest safety demands
- Obstacle detection detects an object through contact and stops the opening or closing process
- Automatic reversing detects an obstacle and returns to the opening position
- Push & Go function triggers the automatic drive following light manual pressure on the door leaf
- Drive can be used with roller guide rail or link arm
- Servo function for motorized support when manually opening the door
- Optional radio board for wireless activation by radio transmitter
- Smoke switch control unit can be connected, whose signal makes the door close automatically in the event of a fire
- Freely configurable inputs and outputs for different functions
- Can be networked, and integrated into the building automation via open standard (BACnet)
Electromechanical swing door drive system for 2-leaf fire and smoke protection doors with closing sequence control
Application Areas
- Fire and smoke protection doors
- Hold-open systems with integrated hold-open function – country-specific specifications must be observed
- Right and left double leaf single-action doors
- Single-action doors up to 3200 mm hinge clearance, 1600 mm leaf width and 600 kg weight
- Minimum hinge clearance 1600 mm
- Interior and exterior doors with high access frequency
- Transom installation hinge and opposite hinge side
Installation situations in reference objects and videos
Technical data
| Powerturn F-IS | |
| Leaf weight (max.) 1-leaf | 600 kg |
| Hinge clearance (min.-max.) 2-leaf, link arm | 1600 mm - 3200 mm |
| Hinge clearance (min.-max.) 2-leaf, roller guide rail | 1600 mm - 2800 mm |
| Leaf width (min.-max.) | 800 mm - 1600 mm |
| Minimum passive leaf width | 800 mm |
| passive leaf width max. | 1600 mm |
| active leaf width min. | 800 mm |
| active leaf width max. | 1600 mm |
| Reveal depth (max.) | 300 mm |
| Opening angle (max.) | 136 ° |
| DIN left | Yes |
| DIN right | Yes |
| Transom installation opposite hinge side with link arm | Yes |
| Transom installation opposite hinge side with roller guide rail | Yes |
| Transom installation hinge side with roller guide rail | Yes |
| Mechanical latching action | Yes |
| Electrical latching action | Yes |
| Electrical closing sequence control | Yes |
| Mechanical closing sequence control | Yes |
| Disconnection from mains | Main switch in the drive |
| Power supply for external consumers (24 V DC) | 1.2 A |
| Service temperature | -15 - 50 °C |
| Mode of operation | Automatic, Off, Permanently open, Shop closing, Night |
| Automatic function | Yes |
| Low-energy function | Yes |
| function smart swing | Yes |
| Servo function | Yes |
| Obstacle detection | Yes |
| Automatic reversing | Yes |
| Push & Go | adjustable |
| Operation | Programme switch DPS, Programme switch integrated in the drive, Programme switch MPS |
| Standard conformity | DIN 18650, EN 16005 |
| Suitability for fire protection doors | Yes |
